Welcome to the third and final part of the blog series. Although Part 1 and Part 2 are not essential for understanding this article, they provide a solid foundation and practical examples for testing the web and service layers.

As explained in the previous articles, we use slice tests specifically to test isolated layers of our application. They do not replace integration tests, but complement them in a meaningful way by expanding our test coverage in a targeted and efficient manner.

Focus of this section: Testing the repository layer

The repository class forms the interface between the Spring Boot application and the underlying database – and is therefore an essential component of the business logic. For this reason, this layer should also be secured by tests.

A central example in this article is the findAllByTitle method. This returns all posts paginated that:

• contain the transferred search term in the title (case insensitive)
• were created within a defined LocalDateTime window

The method uses the annotation @Query to define its own JPQL query. Alternatively, we could also let Spring Data JPA generate queries from method names independently – see the official documentation. As we return a page, a countQuery must also be specified. This counts the total hits for the pagination – otherwise Spring would not be able to calculate the page size correctly.

Note: The JPA repository is completely sufficient for simple filter and search operations. For more complex queries or full-text searches, the use of external tools such as OpenSearch would be my choice.

It should also be noted that JpaRepository is not used directly here, but rather BaseJpaRepository from the Hypersistence Utils Library. This repository interface was developed to avoid so-called repository anti-pattern. You can find out more about this in Vlad Mihalcea’s blog post and his Github Repository.

@Repository
public interface PostRepository extends BaseJpaRepository<Post, UUID>,
    ListPagingAndSortingRepository<Post, UUID> {

  @Query(value = """
      SELECT p
      FROM Post p
      WHERE (LOWER(p.title) LIKE LOWER(CONCAT('%', :title, '%')))
      AND (p.createdAt >= :from)
      AND (p.createdAt <= :to)
      ORDER BY p.createdAt DESC
      """,
      countQuery = """
          SELECT COUNT(p)
          FROM Post p
          WHERE (LOWER(p.title) LIKE LOWER(CONCAT('%', :title, '%')))
          AND (p.createdAt >= :from)
          AND (p.createdAt <= :to)
          """)
  Page<Post> findAllByTitle(
      @Param("title") String title,
      @Param("from") LocalDateTime from,
      @Param("to") LocalDateTime to,
      Pageable pageable);

// ... other Code ...
}

Repository tests: What to look out for?

So how do we test this method in a meaningful and practical way?

Here are a few basic recommendations:

1. Do not test directly against production environments – not even against QA or Dev (in the first run).
2. Tests should be executable locally – ideally even independent of the network connection or infrastructure.
3. Minimise dependencies – the tests should be easily reproducible on every developer computer.

Our solution of choice ist Testcontainers. Testcontainers offers a way to run tests with real, containerised databases. Instead of accessing external database instances, we start a Docker instance with a defined database image for each test run. The big advantage: the database is always consistent and independent of the host system. This means that the test environment always remains the same – reproducible, stable and quickly ready for use.

Structure of the test class

Before we create our test class, we need a small preparatory measure in the test directory. We need to define our own start class (TestMain) so that Testcontainers works correctly in combination with Spring Boot:

public class TestMain {
  public static void main(String[] args) {
       SpringApplication
          .from(Main::main)
          .with(TestcontainersConfiguration.class)
          .run(args);
  }
}

Annotations of the test class

In the following, I will explain the most important annotations that our test class requires:

• @DataJpaTest: This annotation defines the slice test for database access. It does not load the entire Spring Context, but only the components relevant for JPA.
• @Testcontainers: Activates the use of test containers in the test. Docker containers can thus be started automatically when the test is started.
• @AutoConfigureTestDatabase(replace = Replace.NONE): @DataJpaTest implicitly includes an auto configuration for in-memory databases. However, since we use an external database via test containers, this annotation prevents Spring from forcing its own (non-configured) data source – otherwise an error message would be displayed.
• @EnableJpaRepositories: This annotation is only necessary if – as in my case – you are not using the standard JpaRepository but, for example, the BaseJpaRepository from Hypersistence Utils. The repository configuration is not loaded automatically in slice tests, so it must be specified manually.
• @TestInstance(TestInstance.Lifecycle.PER_CLASS): Enables the use of non-static methods with @BeforeAll, as already explained in the second part of the series.

@DataJpaTest
@Testcontainers
@AutoConfigureTestDatabase(replace = Replace.NONE)
@EnableJpaRepositories(
    value = "net.fungiloid*",
    repositoryBaseClass = io.hypersistence.utils.spring.repository.BaseJpaRepositoryImpl.class
)
@TestInstance(TestInstance.Lifecycle.PER_CLASS)
class PostServiceTest {
  @Autowired
  PostRepository postRepository;

  @Autowired
  UserRepository userRepository;
  ...
}

Since @DataJpaTest loads part of the Spring context, we can simply inject our repositories via @Autowired. Spring recognises these and provides them automatically in the test context.

Database container with Testcontainer

  @Container
  @ServiceConnection
  static PostgreSQLContainer<?> postgres = new PostgreSQLContainer<>("postgres:16");

• @Container: Identifies the resource as a test container that is automatically started at the beginning of the test and shut down again at the end.
• @ServiceConnection: This annotation ensures the automatic connection of the Spring Boot Application Context with the database in the container.

Optionally, connection properties can also be set manually – the annotation @DynamicPropertySource can be used for this. An example of this can be found in the official test container documentation. (Equally helpful: the modules overview contains many practical examples for various technologies)

Test the connection

@DataJpaTest
@Testcontainers
@AutoConfigureTestDatabase(replace = Replace.NONE)
@EnableJpaRepositories(
    value = "net.fungiloid*",
    repositoryBaseClass = io.hypersistence.utils.spring.repository.BaseJpaRepositoryImpl.class
)
@TestInstance(TestInstance.Lifecycle.PER_CLASS)
class PostRepositoryTest {

  @Autowired
  PostRepository postRepository;

  @Autowired
  UserRepository userRepository;

  @Container
  @ServiceConnection
  static PostgreSQLContainer<?> postgres = new PostgreSQLContainer<>("postgres:16");

  @Test
  void connectionEstablished() {
    assertThat(postgres.isCreated()).isTrue();
  }
}

Setup: Preparation of the test data

Before we turn our attention to the actual test cases, let’s take a look at the setup – the preparatory steps that ensure that each test runs under consistent conditions.

1. creation of a dummy user

As the post-model expects a user as author, we create a dummy user once before starting all tests. This is done in the method annotated with @BeforeAll:

@BeforeAll
void setup() {
  user = userRepository.persist(
      new User()
          .setDisplayName("test-user")
          .setKey("test-key")
          .setEmail("test.hall@gmx.de")
          .setFirstName("firstname")
          .setLastName("lastname"));
}

This user serves as the creator of all posts that are used in the tests.

2. cleaning up and creating new test data before each test

To ensure that all tests run independently of each other and always start with the same initial data, we delete existing posts at the start of each test and create new ones:

@BeforeEach
void clearPosts() {
    postRepository.deleteAllByIdInBatch(postIds);
    postIds = populateDateRangePosts(LocalDateTime.now());
    entityManager.flush();
}

Insert: Dealing with the createdAt timestamp

The createdAt field in the post entity stores the creation date of a post and is provided with the annotation @CreationTimestamp:

public class Post implements Taggable, Categorizable {
  // ... more code

  @CreationTimestamp
  @Column(name = "created_at", nullable = false, updatable = false)
  private LocalDateTime createdAt;

  // ... more code

}

This annotation ensures that the current timestamp is automatically set when a new Post object is persisted. However, this is a hindrance for our tests, as we want to specifically check whether the repository method filters correctly according to time periods. To do this, we need defined, controllable values for createdAt.

To tackle this problem, we set the timestamp directly in the database using a native query – despite the fact that the field is actually unchangeable (updatable = false). In this way, we can ensure that every test works with the same time-stamped data.

private List<UUID> populateDateRangePosts(LocalDateTime now) {
    Post post1 = new Post();
    post1.setTitle("First Post");
    post1.setCreator(user);
    post1 = postRepository.persist(post1);
    updateCreatedAt(post1, now.minusDays(3));

    Post post2 = new Post();
    post2.setTitle("Second Post");
    post2.setCreator(user);
    post2 = postRepository.persist(post2);
    updateCreatedAt(post2, now.minusDays(2));

    Post post3 = new Post();
    post3.setTitle("Third Post");
    post3.setCreator(user);
    post3 = postRepository.persist(post3);
    updateCreatedAt(post3, now.minusDays(1));

    return List.of(post1.getId(), post2.getId(), post3.getId());
}

private void updateCreatedAt(Post post, LocalDateTime newCreatedAt) {
    entityManager.createNativeQuery("UPDATE post SET created_at = ?1 WHERE id = ?2")
        .setParameter(1, newCreatedAt)
        .setParameter(2, post.getId())
        .executeUpdate();
    entityManager.flush();
    entityManager.clear();
}

The test class therefore looks like this:

@DataJpaTest
@Testcontainers
@AutoConfigureTestDatabase(replace = Replace.NONE)
@EnableJpaRepositories(
    value = "net.fungiloid*",
    repositoryBaseClass = io.hypersistence.utils.spring.repository.BaseJpaRepositoryImpl.class
)
@TestInstance(TestInstance.Lifecycle.PER_CLASS)
public class PostRepositoryTest {
  @Autowired
  PostRepository postRepository;
  @Autowired
  UserRepository userRepository;
  @Container
  @ServiceConnection
  static PostgreSQLContainer<?> postgres = new PostgreSQLContainer<>("postgres:16");

  @Autowired
  EntityManager entityManager;

  User user;
  List<UUID> postIds = List.of();

  @BeforeAll
  void setup() {
    user = userRepository.persist(
        new User()
            .setDisplayName("test-user")
            .setKey("test-key")
            .setEmail("test.hall@gmx.de")
            .setFirstName("firstname")
            .setLastName("lastname"));
  }

  @BeforeEach
  void clearPosts() {
    postRepository.deleteAllByIdInBatch(postIds);
    postIds = populateDateRangePosts(LocalDateTime.now());
    entityManager.flush();
  }

  @Test
  void connectionEstablished() {
    assertThat(postgres.isCreated()).isTrue();
  }

  private List<UUID> populateDateRangePosts(LocalDateTime now) { ... }

  private void updateCreatedAt(Post post, LocalDateTime newCreatedAt) { ... }
}

Testcases

Once we have completed the configuration for slice tests and test containers, we can now specifically test the repository logic – specifically the findAllByTitle method, which filters by title and also takes a time period into account.

Goal of the test

The repository method should:

• return posts whose titles contain a specific string (case insensitive),
• only consider results in the specified time period,
• paginate the results and sort by createdAt descending order.

Test case: Filtering by title

This test checks whether the repository method filters correctly for a specific title – regardless of capitalisation. As only one post has exactly this title, we expect exactly one result. (getEffectiveDateRange(null, null) returns an array of LocalDateTime ranging from 1960 to now)

@Test
@DisplayName("Filter posts by title: Only matching posts are returned")
void shouldReturnPost_WhenTitleMatchesExactly() {
    Pageable pageable = PageRequest.of(0, 10);
    Page<Post> result = postRepository.findAllByTitle(
        "First Post",
        getEffectiveDateRange(null, null)[0],
        getEffectiveDateRange(null, null)[1],
        pageable);

    assertThat(result.getTotalElements()).isEqualTo(1);
    Post found = result.getContent().get(0);
    assertThat(found.getTitle()).containsIgnoringCase("First Post");
}

Test case: Combination of title & time filter with sorting

Here we test:

• Whether only posts in the defined time window (2 days back to today) are taken into account.
• Whether the sorting according to createdAt DESC works correctly.

Two hits are expected (“Third Post” and “Second Post”), with “Third Post” being the most recent.

@Test
@DisplayName("Filter posts by title and date range: Correct posts are returned in sorted order")
void shouldReturnPostsInCorrectOrder_WhenFilteringByTitleAndDateRange() {
    LocalDateTime now = LocalDateTime.now();
    Pageable pageable = PageRequest.of(0, 10);
    LocalDateTime from = now.minusDays(2).toLocalDate().atStartOfDay();
    Page<Post> result = postRepository.findAllByTitle("Post", from, now, pageable);

    assertThat(result.getTotalElements()).isEqualTo(2);
    List<Post> posts = result.getContent();
    assertThat(posts.get(0).getCreatedAt()).isAfter(posts.get(1).getCreatedAt());
    assertThat(posts.get(0).getTitle()).isEqualTo("Third Post");
    assertThat(posts.get(1).getTitle()).isEqualTo("Second Post");
}

Test case: No hit due to unsuitable time period

In this case, the specified time period is outside the creation time of all existing posts.

@Test
@DisplayName("No posts are found due to non-matching date range")
void shouldReturnNoPosts_WhenDateRangeDoesNotMatchAnyPost() {
    LocalDateTime now = LocalDateTime.now();
    Pageable pageable = PageRequest.of(0, 10);
    LocalDateTime from = now.minusDays(5).toLocalDate().atStartOfDay();
    LocalDateTime to = now.minusDays(4).toLocalDate().atStartOfDay();
    Page<Post> result = postRepository.findAllByTitle("Post", from, to, pageable);

    assertThat(result.getTotalElements()).isEqualTo(0);
}

Testcase: No hit due to invalid title

In this case, the specified time period is outside the creation time of all existing posts.

@Test
@DisplayName("No posts are found due to invalid title filter")
void shouldReturnNoPosts_WhenTitleDoesNotMatchAnyPost() {
    LocalDateTime now = LocalDateTime.now();
    Pageable pageable = PageRequest.of(0, 10);
    LocalDateTime from = now.minusDays(2).toLocalDate().atStartOfDay();
    Page<Post> result = postRepository.findAllByTitle("NoValidPostTitle", from, now, pageable);

    assertThat(result.getTotalElements()).isEqualTo(0);
}

Conclusion

These tests demonstrate how slice tests and test containers can be used to specifically validate the repository layer – with a high level of control over the test data, complete isolation and a reproducible environment.

The advantages:

• Clear delimitation of the tested layer
• No overhead due to the complete Spring Context
• Realistic database environment due to test containers

To make the whole thing more practical,  I have prepared a very simplified example application based on Spring Boot. So you can follow every step of the series hands-on and test it directly yourself.

This is the second part of the three-part blog series. The first part is not essential for understanding this post, but is highly recommended as it provides a better overall understanding, practical examples of web layer testing and a brief overview of the application architecture.

As discussed there, we focus on slice tests to specifically test individual layers of our architecture. These do not replace integration tests – rather, they extend our test coverage in a targeted and efficient way.

Focus of this section: Service layer test

The service layer forms the centrepiece of an application’s business logic. To test it specifically, let’s take a look at the update() method, which can be used to update an existing post.

The update() method has three parameters:

• UUID id – identifies the post that is to be updated
• UpdatePostDTO – holds the new data for the post
• JwtAuthenticationToken – stands for the currently authenticated use

Functionality of the update() method:

• The author of the post is determined using the ID of the post
• It is checked whether the current user is either the author himself or an admin
• The post is overwritten with the new data if the authorisation check was successful

@Transactional
@Service
class PostService {
// PostService.java

// ... other Imports und Code ...
@Autowired
UserService userService;
@Autowired
PostRepository postRepository;
@Autowired
Utils utils;

    public Either<ErrorJson, Post> update(
            UUID id,
            UpdatePostDTO updatePostDTO,
            JwtAuthenticationToken jwtAuthenticationToken) {
        return utils.wrapCall(
                        () -> postRepository.findCreatorByPostId(id).orElseThrow(),
                        new ErrorNotFoundInDB("post", updatePostDTO.getId())
                )
                .flatMap(creator -> userService.getAuthorizedCreator(
                        jwtAuthenticationToken, creator.getId()
                ))
                .flatMap(user -> utils.wrapCall(
                        () -> postRepository.update(updateDtoToModel(
                                id,
                                updatePostDTO,
                                user)),
                        new ErrorUnableToSaveToDB("post")
                ));
    }

// ... other Code ...
}

Structure of the test class

Before we dive into the individual test cases, let’s clarify the basic concept of our test class.

We follow an architecture-oriented slice test approach in which each application layer is tested separately. In this section, we focus on isolated unit tests of the service layer. Integration tests will follow in a later part.

In contrast to the web layer test from part 1, here we test completely independently of Spring Boot-specific components. Why is this possible? Because the service layer generally does not require any in-depth Spring abstractions. Although we use @Autowired, we can easily mock the dependencies with Mockito.

Mockito-Integration mit @ExtendWith

@ExtendWith(MockitoExtension.class)
class PostServiceTest {
  ...
}

This allows us to add @Mock annotation to fields (instead of mocking manually) and @InjectMocks ensures that Mockito automatically injects the dependencies. It should be noted that, depending on your Spring Boot version, the syntax.

@ExtendWith(MockitoExtension.class)
class PostServiceTest {
    @Mock
    private UserService userService;
    @Mock
    private Utils utils;
    @InjectMocks
    private PostService postService;
}

Preparation of the test with lifecycle annotations

In our tests, we need a JwtAuthenticationToken, among other things. As this is not part of the logic to be tested, we can simply mock it. We use @BeforeAll in combination with mock() for this. (It should be noted here that the JWT could also be mocked using @Mock. The Lifecylce method is used to display various functionalities.)

@TestInstance(TestInstance.Lifecycle.PER_CLASS)
@ExtendWith(MockitoExtension.class)
class PostServiceTest {
    @Mock
    private UserService userService;
    @Mock
    private Utils utils;
    @InjectMocks
    private PostService postService;

    private JwtAuthenticationToken token;

    @BeforeAll
    void setup() {
        token = mock(JwtAuthenticationToken.class);
    }
}

Normally, the method annotated with @BeforeAll should be static. However, thanks to the annotation @TestInstance(TestInstance.Lifecycle.PER_CLASS), it can also be non-static.

Insert: JUnit 5 lifecycle annotations at a glance

Annotation	When is it called?	How often?
@BeforeEach |individual test	Before each	Per test
@AfterEach	After each individual test	Per test
@BeforeAll	Once before all tests in the class	1x
@AfterAll	Once after all tests in the class	1x

Test cases

Test case: Successful update of a post

In this test case, we check whether the update() method works correctly in a positive test case. And this is the case if the post exists, the user is authorised and the update is successfully carried out in the database.

@TestInstance(TestInstance.Lifecycle.PER_CLASS)
@ExtendWith(MockitoExtension.class)
class PostServiceTest {
    @Mock
    private UserService userService;
    @Mock
    private Utils utils;
    @InjectMocks
    private PostService postService;

    private JwtAuthenticationToken token;

    @BeforeAll
    void setup() {
        token = mock(JwtAuthenticationToken.class);
    }

    @Test
    @DisplayName("Should update post successfully")
    void shouldUpdatePost_whenUserIsAuthorized_andPostExists() {
        when(utils.wrapCall(any(CheckedFunction0.class), any(ErrorJson.class)))
                .thenReturn(Either.right(mockUser))
                .thenReturn(Either.right(mockPost));

        when(userService.getAuthorizedCreator(token, mockUser.getId()))
                .thenReturn(Either.right(mockUser));

        Either<ErrorJson, Post> result = postService.update(postId, dto, token);

        verify(userService).getAuthorizedCreator(token, mockUser.getId());
        verify(utils, times(2))
                .wrapCall(any(CheckedFunction0.class), any(ErrorJson.class));

        assertThat(result.isRight()).isTrue();
        assertThat(result.get().getId()).isEqualTo(postId);
    }
}

Analyse the update() method

The method to be tested is located in the PostService.

    public Either<ErrorJson, Post> update(
            UUID id,
            UpdatePostDTO updatePostDTO,
            JwtAuthenticationToken jwtAuthenticationToken) {
        return utils.wrapCall(
                        () -> postRepository.findCreatorByPostId(id).orElseThrow(),
                        new ErrorNotFoundInDB("post", updatePostDTO.getId())
                )
                .flatMap(creator -> userService.getAuthorizedCreator(
                        jwtAuthenticationToken, creator.getId()
                ))
                .flatMap(user -> utils.wrapCall(
                        () -> postRepository.update(updateDtoToModel(
                                id,
                                updatePostDTO,
                                user)),
                        new ErrorUnableToSaveToDB("post")
                ));
    }

Step 1: Mock findCreatorByPostId

utils.wrapCall(
    () -> postRepository.findCreatorByPostId(id).orElseThrow(),
    new ErrorNotFoundInDB("post", updatePostDTO.getId())
)

In the test, this call is mocked as follows.

when(utils.wrapCall(any(CheckedFunction0.class), any(ErrorJson.class)))
        .thenReturn(Either.right(mockUser))

This means that the first time wrapCall is called, a mockUser is returned – the author of the post.

Step 2: Authorisation check

The method checks whether the user is authorised to make changes:

.flatMap(creator -> userService.getAuthorizedCreator(
            jwtAuthenticationToken,
            creator.getId()
        ))

The matching mock definition.

when(userService.getAuthorizedCreator(token, mockUser.getId()))
        .thenReturn(Either.right(mockUser));

The user is authorised – we are simulating the successful case here.

Step 3: Update in the database

The actual saving of the updated post looks like this.

.flatMap(user -> utils.wrapCall(
        () -> postRepository.update(updateDtoToModel(id, updatePostDTO, user)),
        new ErrorUnableToSaveToDB("post")
));

In the test, this is also mapped using wrapCall. As wrapCall was already used for the first step, we specify two returns in succession:

when(utils.wrapCall(any(CheckedFunction0.class), any(ErrorJson.class)))
        .thenReturn(Either.right(mockUser))
        .thenReturn(Either.right(mockPost));

Schritt 4: Assertions and verifications

At the end, we check whether our expectations have been met – both in terms of content and methodological execution:

verify(userService).getAuthorizedCreator(token, mockUser.getId());
verify(utils, times(2))
    .wrapCall(any(CheckedFunction0.class), any(ErrorJson.class));

assertThat(result.isRight()).isTrue();
assertThat(result.get().getId()).isEqualTo(postId);

The assertions ensure that:

• The correct path has been traversed (mocks have been called)
• The result is a successful -> Either.right(Post)
• The returned post ID matches the expected one

Other test cases: negative

In addition to successfully testing the happy path, it is also important to cover error scenarios. These negative test cases ensure that our application behaves correctly even if something goes wrong or is not permitted.

We will test three typical problem cases below:

Test case: Post does not exist

In this test, we simulate the case where the post for the specified ID is not found in the database. In this case, the wrapCall() method returns an Either.left with a suitable ErrorJson.

We expect that:

• No access to userService takes place, as the process is cancelled beforehand
• The error is correctly returned to the caller

@Test
@DisplayName("Should return error if post does not exist")
public void shouldReturnError_whenPostDoesNotExist() {
    ErrorJson notFound = new ErrorJson("Not Found", "Post not found", 404);

    when(utils.wrapCall(any(CheckedFunction0.class), any(ErrorJson.class)))
            .thenReturn(Either.left(notFound));

    Either<ErrorJson, Post> result = postService.update(postId, dto, token);

    verify(utils)
            .wrapCall(any(CheckedFunction0.class), any(ErrorJson.class));
    verifyNoInteractions(userService);

    assertThat(result.isLeft()).isTrue();
    assertThat(result.getLeft().getStatus()).isEqualTo(404);
}

Test case: User is not authorised

This checks what happens if the current user is not authorised to edit the post. In this case too, the getAuthorisedCreator() method returns an Either.left with an error object.

We make sure that:

• The authorisation step is executed
• But no attempt is made to save the post
• A corresponding 403 error is returned

@Test
@DisplayName("Should return error if user not authorized")
public void shouldReturnError_whenUserIsNotAuthorized() {
    when(utils.wrapCall(any(CheckedFunction0.class), any(ErrorJson.class)))
            .thenReturn(Either.right(mockUser));

    ErrorJson unauthorized = new ErrorJson("Access Denied", "You do not have permission", 403);

    when(userService.getAuthorizedCreator(token, mockUser.getId()))
            .thenReturn(Either.left(unauthorized));

    Either<ErrorJson, Post> result = postService.update(postId, dto, token);

    verify(utils).wrapCall(any(CheckedFunction0.class), any(ErrorJson.class));
    verify(userService).getAuthorizedCreator(token, mockUser.getId());

    assertThat(result.isLeft()).isTrue();
    assertThat(result.getLeft().getStatus()).isEqualTo(403);
}

Test case: Database error when saving

Even if all the previous steps are successful, saving to the database can still fail. This test simulates exactly this case: wrapCall() during the save process returns an Either.left with a DB-specific error.

We check that:

• All steps are completed
• The error from the last wrapCall() is correctly propagated to the caller

@Test
@DisplayName("Should return error if DB update fails")
public void shouldReturnError_whenUpdateFailsDueToDatabaseError() {
    ErrorJson dbError = new ErrorJson("DB Error", "Could not save post", 500);

    when(utils.wrapCall(any(CheckedFunction0.class), any(ErrorJson.class)))
            .thenReturn(Either.right(mockUser))
            .thenReturn(Either.left(dbError));

    when(userService.getAuthorizedCreator(token, mockUser.getId()))
            .thenReturn(Either.right(mockUser));

    Either<ErrorJson, Post> result = postService.update(postId, dto, token);

    verify(utils, times(2))
            .wrapCall(any(CheckedFunction0.class), any(ErrorJson.class));
    verify(userService).getAuthorizedCreator(token, mockUser.getId());

    assertThat(result.isLeft()).isTrue();
    assertThat(result.getLeft().getStatus()).isEqualTo(500);
}

Conclusion

In this section, we have shown how the service layer of a multi-tier Spring application can be tested. In doing so, we deliberately avoided Spring-specific features. The result: lean, high-performance and easy-to-read unit tests.

By using Mockito, we were able to easily mock external dependencies and test the service logic in isolation. AssertJ was used to verify the results.

In the next part of the series, we will learn how we can use test containers to test the repository layer of our Spring Boot application against a real database.

To make the whole thing more practical,  I have prepared a very simplified example application based on Spring Boot. So you can follow every step of the series hands-on and test it directly yourself.

This is the first part of a three-part series that provides a practical introduction to testing Spring Boot applications. A social media app I developed serves as an example. The focus is on the post service, which maps the central business logic around posts.

What can the Post Service do?

• Creators can create, edit, delete and retrieve posts
• Users may only read posts

Architecture of the application

The application follows a classic layered architecture:

• RestController – defines the HTTP endpoints
• Service – contains the business logic
• Repository – communicates with the database

System overview

The overall system consists of three main components:

• API Gateway
• Keycloak + Identity Provider (IDP)
• REST-API (Social Media App)


Focus of this section: Web layer tests

This section centres on testing the web layer, in particular the RestController. The following code snippet shows an excerpt from the PostController and the PostService:

// PostController.java

// ... other Imports and Code ...

@Autowired
private PostService postService;

@Autowired
private Utils utils;

@PreAuthorize("hasAnyAuthority('ROLE_CREATOR', 'ROLE_ADMIN')")
@PostMapping(
    produces = MediaType.APPLICATION_JSON_VALUE,
    consumes = MediaType.APPLICATION_JSON_VALUE
)
public ResponseEntity<?> create(
        JwtAuthenticationToken jwtAuthenticationToken,
        @RequestBody PostDTO postDTO
) {
    return utils.fold201(
        postService.save(postDTO, jwtAuthenticationToken)
            .map(post -> postService.modelToSingleResponseDTO(post))
    );
}

// ... other Code ...

// PostService.java

// ... other Imports und Code ...

@Transactional
public Either<ErrorJson, Post> save(PostDTO postDTO, JwtAuthenticationToken jwtAuthenticationToken) {
    return userService.getUserFromToken(jwtAuthenticationToken)
            .flatMap(user ->
                utils.wrapCall(
                    () -> postRepository.persist(DTOToModel(postDTO, user)),
                    new ErrorUnableToSaveToDB("post")
                )
            );
}

// ... other Code ...

Structure of the test class

Before we look at the test cases in detail, we will first define the basic concept of our test class.

We follow a layered test approach that is orientated towards the architecture of the application. In this section, we focus on unit tests of the controller. Integration tests will follow later.

Especially with more complex applications, it is often impractical to test the controllers completely isolated from their dependencies. However, as the focus here is clearly on the behaviour of the controller, it is justified from a pragmatic point of view to continue to consider these tests as unit tests.

Test context and annotations

Spring loads an ApplicationContext for each test run, which can be time-consuming. It therefore makes sense:

• Have as few different test contexts as possible → Use caching effects
• Keep the contexts as small as possible → faster tests

Since we only want to test the web layer at this point (not the entire application), we use a slice test with:

@WebMvcTest(controllers = PostController.class)
public class PostControllerTest {}

Why not @SpringBootTest?

@SpringBootTest
@AutoConfigureMockMvc
public class PostControllerTest {}

This combination loads the entire ApplicationContext, including database, services, repositories etc. – which is unnecessary and inefficient if only a single controller is to be tested. @WebMvcTest is much leaner and more targeted here.

Regardless of whether we use @SpringBootTest or @WebMvcTest, no real web server is started during the test runs. The explicit use of @SpringBootTest is an exception: @SpringBootTest(webEnvironment = SpringBootTest.WebEnvironment.RANDOM_PORT). In this case, a web server is actually started – which can be helpful in certain debugging scenarios. However, this is not necessary for our purposes.

Although no web server is running, we need a tool to send HTTP requests to our controller. This is where MockMvc or from Spring Boot 3.4 the MockMvcTester comes into play. These tools make it possible to simulate HTTP requests as if they were arriving via the network. The responses can then be checked using Hamcrest (classic) or AssertJ (from Spring Boot 3.4).

Test of the web layer

The tests focus on the external interface of our application – the web layer, specifically the PostController. But why is it even worth testing this layer separately? In many cases, there is a risk that security rules, routing errors or simple annotations such as @PreAuthorise, @RequestBody, @PostMapping etc. are implicitly assumed to work. In reality, however, it is often the case that:

• Access rights are inadvertently set incorrectly (ROLE_USER instead of ROLE_CREATOR)
• Security concepts such as CSRF or JWT verification are misconfigured
• Controllers react too tolerantly or too restrictively to requests

With web layer tests like this one, we have the opportunity to recognise these problems early on in the development process. And additionally because the test does not load the entire application, but only focuses on the controller (@WebMvcTest), it is lightweight and very fast.

We can therefore summarise – these tests are valuable in the context of:

• Security & authorisation → Do we make sure that only certain roles really have access?
• Request structure & validation → How does the endpoint behave if fields are missing, the format is incorrect or the content type is invalid?
• Error tolerance & response handling → Is an error handled correctly (e.g. 403 Forbidden, 400 Bad Request, 415 Unsupported Media Type)?

These tests are no substitute for integration tests – but they provide a high level of security with little effort.

@WebMvcTest(controllers = PostController.class)
@Import(SecurityConfig.class)
class PostControllerTest {
    @Autowired
    private MockMvcTester mockMvc;

    @MockitoBean
    private PostService postService;

    @TestConfiguration
    static class TestConfig {
        @Bean
        public Utils utils() {
            return new Utils();
        }
    }
    // ... other Code ...
}

If we look at the controller shown at the beginning, we recognise two dependencies: the PostService and the Utils class.

Since we are not testing the service itself, but only the controller, we need to mock the PostService. This is done using the annotation @MockitoBean, whereby Spring automatically registers a mock object and injects it into the controller.

We could also have mocked the Utils class in this way. In this case, however, I decided to bring the real implementation into the test context. To do this, we use a @TestConfiguration in which the Utils instance is defined as a bean. This configuration is read in when the test is started and the bean is automatically registered. As the Utils class is @Autowired in the controller, it is injected correctly.

Another important point: In the controller, we secure the endpoints using @PreAuthorise. In order for this access control to work correctly in the test environment, our own SecurityConfig must be explicitly imported into the slice test. Otherwise, Spring will not load a complete security configuration as part of @WebMvcTest, which can lead to unexpected behaviour – such as failed authorisations despite a correct setup.

Brief overview: Authentication and authorisation flow

• The user first authenticates himself via Keycloak
• After successful login, the user receives a bearer token (JWT)
• Our SecurityConfig defines how the JWT is processed: We extract the user role from the resource_access.roles claim
• Depending on this role (e.g. ROLE_ADMIN, ROLE_CREATOR, ROLE_USER), Spring Security decides whether a specific controller endpoint may be called
• The resulting JwtAuthenticationToken is automatically available as a parameter in the controller and contains all relevant information about the user

Test cases

Test case: Successful creation of a post

Let’s now look at the first test case. This tests the successful creation of a post via the corresponding POST endpoint.

@WebMvcTest(controllers = PostController.class)
@Import(SecurityConfig.class)
class PostControllerTest {

    @Autowired
    private MockMvcTester mockMvc;

    @MockitoBean
    private PostService postService;

    @TestConfiguration
    static class TestConfig {
        @Bean
        public Utils utils() {
            return new Utils();
        }
    }

    @Test
    @DisplayName("Successfully: POST with ROLE_CREATOR")
    void createPost_successfulAsCreator() throws Exception {
        UUID userId = UUID.randomUUID();
        UUID postId = UUID.randomUUID();
        Post mockPost = createMockPost(postId, createMockUser(userId));

        when(postService.save(
                ArgumentMatchers.any(PostDTO.class),
                ArgumentMatchers.any(JwtAuthenticationToken.class))
        ).thenReturn(Either.right(mockPost));

        when(postService.modelToSingleResponseDTO(
                ArgumentMatchers.any(Post.class))
        ).thenAnswer(invocation -> {
            Post post = invocation.getArgument(0);
            return createResourceResponse(post);
        });

        mockMvc.post()
                .uri("/posts")
                .content(buildPostRequest().toString())
                .contentType(MediaType.APPLICATION_JSON)
                .with(csrf())
                .with(jwt().authorities(new SimpleGrantedAuthority("ROLE_CREATOR")))
                .exchange()
                .assertThat()
                .hasStatus(HttpStatus.CREATED)
                .hasContentType(MediaType.APPLICATION_JSON)
                .bodyJson()
                .hasPathSatisfying("$.data.item.title", path ->
                        path.assertThat().isEqualTo("Mock Title"))
                .hasPathSatisfying("$.data.item.description", path ->
                        path.assertThat().isEqualTo("Description"));
    }

    // ... other tests or helper methods...
}

When the endpoint is called, the save method of the PostService is first called in the controller. If successful, this returns a Post object. Afterwards, the modelToSingleResponseDTO method is called in the service to transform the returned Post object into a response DTO.

Since we mocked the PostService in the test, these methods would return null by default – or even throw a NullPointerException if their return values are reused. To avoid this, we need to explicitly tell Mockito what should happen when these methods are called.

1. postService.save(…)
Here we define that a call with any arguments (any(PostDTO.class) and any(JwtAuthenticationToken.class)) returns a prepared mockPost:

   when(postService.save(...)).thenReturn(Either.right(mockPost));

2. postService.modelToSingleResponseDTO(…)
This method is then called with the result of the save call (i.e. the mockPost). We use thenAnswer(…) instead of thenReturn(…), as we want to dynamically read the transferred post from the mock service in order to generate a DTO from it.

when(postService.modelToSingleResponseDTO(any(Post.class)))
  .thenAnswer(invocation -> {
      Post post = invocation.getArgument(0);
      return createResourceResponse(post);
  });

This ensures that the controller runs through its logic correctly and that a fully constructed response object is generated.

csrf()
As Spring Security activates CSRF protection by default, we must explicitly include a CSRF token in the test for state-changing HTTP requests such as POST, PUT or DELETE. If this is omitted, Spring rejects the request with a 403 Forbidden – even if the authentication is correct. The .with(csrf()) method ensures that a valid CSRF token is simulated and sent in the test.

jwt()
As our endpoints are secured with @PreAuthorise, Spring Security expects an authenticated context. We use .with(jwt()) to simulate a valid JWT-based login. In addition, we can use .authorities(…) to assign specific roles in order to test various access scenarios such as ROLE_USER, ROLE_CREATOR or ROLE_ADMIN.

3. assertThat()
The assertThat() method returns an MvcTestResultAssert object, which we can then use to formulate our assertions. The MockMvcTester API offers a more modern and much more readable syntax than the classic MockMvc, which relies on many static methods and a chained .andExpect(…) structure.

 // example: mockMvc with hamcrest

mockMvc.perform(post("/posts")
        .with(csrf())
        .with(jwt().authorities(new SimpleGrantedAuthority("ROLE_CREATOR")))
        .content(buildPostRequest().toString())
        .contentType(MediaType.APPLICATION_JSON))
    .andExpect(status().isCreated())
    .andExpect(content().contentType(MediaType.APPLICATION_JSON))
    .andExpect(jsonPath("$.data.item.title").value("Mock Title"))
    .andExpect(jsonPath("$.data.item.description").value("Description"));

// example: mockMvcTester with assertJ
mockMvc.post()
       .uri("/posts")
       .content(buildPostRequest().toString())
       .contentType(MediaType.APPLICATION_JSON)
       .with(csrf())
       .with(jwt().authorities(new SimpleGrantedAuthority("ROLE_CREATOR")))
       .exchange()
       .assertThat()
       .hasStatus(HttpStatus.CREATED)
       .hasContentType(MediaType.APPLICATION_JSON)
       .bodyJson()
       .hasPathSatisfying(
            "$.data.item.title",
             path ->path.assertThat().isEqualTo("Mock Title")
        )
       .hasPathSatisfying(
            "$.data.item.description",
            path -> path.assertThat().isEqualTo("Description")
        );

Further test cases incorrect and unauthorised access

In addition to the successful happy path test, it is also essential to cover error scenarios. These negative test cases ensure that our application behaves correctly even if something goes wrong or is not permitted. They make a significant contribution to safeguarding the API – especially in the areas of security and validation.

We will test three typical problem cases below:

Access with insufficient role (403 Forbidden)

@Test
@DisplayName("FAILURE: ROLE_USER is not allowed to create a post")
void createPost_forbiddenForUserRole() throws Exception {
    mockMvc.post()
            .uri("/posts")
            .content(buildPostRequest().toString())
            .contentType(MediaType.APPLICATION_JSON)
            .with(csrf())
            .with(jwt().authorities(
                new SimpleGrantedAuthority("ROLE_USER")
             ))
            .exchange()
            .assertThat()
            .hasStatus(HttpStatus.FORBIDDEN);
}

In this test, a user with the ROLE_USER role is simulated. As only ROLE_CREATOR and ROLE_ADMIN may have access to the endpoint (see @PreAuthorise), access is rightly blocked with a 403 Forbidden.

No token available (401 Unauthorised)

@Test
@DisplayName("No Token → 401 Unauthorized")
void createPost_unauthorizedWithoutToken() throws Exception {
    mockMvc.post()
            .uri("/posts")
            .content(buildPostRequest().toString())
            .with(csrf())
            .contentType(MediaType.APPLICATION_JSON)
            .exchange()
            .assertThat()
            .hasStatus(HttpStatus.UNAUTHORIZED);
}

A request is sent here without authentication (no JWT). However, the Spring security configuration requires that only authenticated users have access. Therefore, as expected, we receive the HTTP status 401 Unauthorised.

Incorrect content type (415 Unsupported Media Type)

@Test
@DisplayName("Wrong Content-Type → 415 Unsupported Media Type")
void createPost_unsupportedMediaType() throws Exception {
    mockMvc.post()
            .uri("/posts")
            .content("test=1234")
            .contentType(MediaType.TEXT_PLAIN)
            .with(csrf())
            .with(jwt().authorities(
                new SimpleGrantedAuthority("ROLE_CREATOR")
             ))
            .exchange()
            .assertThat()
            .hasStatus(HttpStatus.UNSUPPORTED_MEDIA_TYPE);
}

In this case, a text/plain request is sent to a JSON endpoint. As the controller explicitly expects application/json (via @PostMapping(…, consumes = MediaType.APPLICATION_JSON_VALUE)),
Spring rejects the request with 415 Unsupported Media Type.

Conclusion

In this part of the series, we showed how the web layer of a Spring Boot application can be tested in isolation using so-called slice tests. Through the targeted use of @WebMvcTest, we were able to focus exclusively on the controller level – without loading the complete ApplicationContext or other layers.

In the next part of the series, we will look at the service layer. There we will learn how we can test the business logic. In the final third part, we will then take a look at integration tests for the repository layer, in which we simulate a real database environment using test containers.

To make the whole thing more practical, I have prepared a very simplified example application based on Spring Boot. So you can follow every step of the series hands-on and test it directly yourself.
